backend

Manim backend for high-quality temporal network animations.

Professional animation backend using Manim Community Edition for creating high-quality temporal network visualizations. Optimized for temporal graphs with smooth transitions and customizable animation parameters.

Features
  • High-quality video output (MP4, GIF)
  • Temporal network animation with smooth transitions
  • Jupyter notebook integration with inline video display
  • FFmpeg integration for format conversion

Workflow Overview

graph LR
    A[Graph Data] --> B[Manim Scene Creation]
    B --> C[Rendering]
    C --> D[MP4 Output]
    D --> E[Conversion]
    E --> F[GIF Output]

ManimBackend

Bases: pathpyG.visualisations.plot_backend.PlotBackend

Manim backend for temporal network animation.

Integrates Manim Community Edition for creating smooth temporal network animations. Supports both MP4 and GIF output formats with Jupyter notebook integration for inline display.

Features
  • Temporal network animation with smooth node/edge transitions
  • Multiple output formats (MP4, GIF via FFmpeg)
  • Jupyter integration with base64 video embedding
Example

Create and display a simple temporal network animation:

import pathpyG as pp

tedges = [("a", "b", 1), ("b", "c", 2), ("c", "a", 3)]
tg = pp.TemporalGraph.from_edge_list(tedges)
pp.plot(tg, backend="manim", filename="temporal_network.gif")
Example Matplotlib Backend Output

Temporal Networks Only

This backend is specifically designed for TemporalNetworkPlot objects and does not support static network visualization.

Performance Requirements

High-quality animations require significant computational resources. Rendering time scales with network size, animation duration, and quality settings.

Source code in src/pathpyG/visualisations/_manim/backend.py
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
class ManimBackend(PlotBackend):
    """Manim backend for temporal network animation.

    Integrates Manim Community Edition for creating smooth temporal network
    animations. Supports both MP4 and GIF output formats with Jupyter notebook
    integration for inline display.

    Features:
        - Temporal network animation with smooth node/edge transitions
        - Multiple output formats (MP4, GIF via FFmpeg)
        - Jupyter integration with base64 video embedding

    Example:
        Create and display a simple temporal network animation:
        ```python
        import pathpyG as pp

        tedges = [("a", "b", 1), ("b", "c", 2), ("c", "a", 3)]
        tg = pp.TemporalGraph.from_edge_list(tedges)
        pp.plot(tg, backend="manim", filename="temporal_network.gif")
        ```
        <img src="../../plot/temporal_network.gif" alt="Example Matplotlib Backend Output" width="550"/>

    !!! note "Temporal Networks Only"
        This backend is specifically designed for TemporalNetworkPlot
        objects and does not support static network visualization.

    !!! warning "Performance Requirements"
        High-quality animations require significant computational resources.
        Rendering time scales with network size, animation duration, and quality settings.
    """

    def __init__(self, plot: PathPyPlot, show_labels: bool):
        """Initialize Manim backend with temporal network validation and configuration.

        Sets up Manim configuration parameters including resolution, frame rate,
        quality settings, and background color. Validates that the plot type
        is supported (currently only TemporalNetworkPlot).

        Args:
            plot: PathPyPlot instance (must be TemporalNetworkPlot)
            show_labels: Whether to display node labels in animation

        Raises:
            ValueError: If plot type is not supported by Manim backend

        !!! info "Manim Configuration"
            Automatically configures Manim settings using pathpyG config and fixed defaults:

            - **Resolution**: From width/height config parameters
            - **Frame Rate**: Default 15 fps for smooth playback
            - **Quality**: High quality
            - **Background**: White background for clarity
        """
        super().__init__(plot, show_labels=show_labels)
        self._kind = SUPPORTED_KINDS.get(type(plot), None)
        if self._kind is None:
            logger.error(f"Plot of type {type(plot)} not supported by Matplotlib backend.")
            raise ValueError(f"Plot of type {type(plot)} not supported.")

        # Optional config settings
        manim_config.pixel_height = int(unit_str_to_float(self.config.get("height"), "px"))  # type: ignore[arg-type]
        manim_config.pixel_width = int(unit_str_to_float(self.config.get("width"), "px"))  # type: ignore[arg-type]
        manim_config.quality = "high_quality"
        manim_config.background_color = WHITE

    def render_video(self) -> tuple[Path, str]:
        """Render temporal network animation using Manim engine.

        Creates temporary directory, configures Manim settings, instantiates
        TemporalGraphScene, and renders the complete animation sequence.
        Handles all Manim-specific setup and teardown.

        Returns:
            tuple: (video_file_path, temp_directory_path) for post-processing

        !!! info "Rendering Pipeline"
            1. **Setup**: Create temporary directory for Manim output
            2. **Configuration**: Set output path and filename
            3. **Scene Creation**: Instantiate TemporalGraphScene with data
            4. **Rendering**: Execute Manim rendering process
            5. **Cleanup**: Return paths for further processing and returns to original directory
        """
        temp_dir, current_dir = prepare_tempfile()
        manim_config.media_dir = temp_dir
        manim_config.output_file = "default.mp4"
        self.scene = TemporalGraphScene(data=self.data, config=self.config, show_labels=self.show_labels)
        self.scene.render()
        os.chdir(current_dir)
        return Path(temp_dir) / "videos" / "1080p60" / "default.mp4", temp_dir

    def save(self, filename: str) -> None:
        """Render and save temporal network animation to specified file.

        Creates high-quality animation video and saves to disk. Supports both
        MP4 and GIF formats with automatic format detection from filename
        extension. GIF conversion uses FFmpeg.

        Args:
            filename: Output file path with extension (.mp4 or .gif)

        !!! warning "GIF Conversion"
            GIF creation requires FFmpeg to be installed and available in PATH.
            Conversion may take additional time for long animations.
        """
        # render temporary .mp4
        temp_file, temp_dir = self.render_video()
        if filename.endswith(".gif"):
            self.convert_to_gif(temp_file)
            temp_file = temp_file.with_suffix(".gif")
        shutil.copy(temp_file, filename)
        shutil.rmtree(temp_dir)

    def convert_to_gif(self, filename: Path) -> None:
        """Convert rendered MP4 video to animated GIF using FFmpeg.

        Uses FFmpeg with optimized settings for web-friendly GIF output:
        30 fps for smooth animation, Lanczos scaling for quality preservation,
        and 1080p resolution maintenance.

        Args:
            filename: Path to source MP4 file (output GIF uses same path with .gif extension)

        Raises:
            Exception: If FFmpeg conversion fails (logged as error)
        """
        try:
            subprocess.run(
                [
                    "ffmpeg",
                    "-i",
                    filename,
                    "-vf",
                    "fps=30,scale=1080:-1:flags=lanczos",
                    "-y",
                    "-hide_banner",
                    "-loglevel",
                    "error",
                    filename.with_suffix(".gif"),
                ],
                check=True,
            )
        except Exception as e:
            logger.error(f"GIF conversion failed: {e}")

    def show(self) -> None:
        """Display temporal network animation in interactive environment.

        Renders animation and displays inline in Jupyter notebooks using base64
        video embedding, or opens in system browser for non-interactive environments.
        Automatically cleans up temporary files after display.
        """
        temp_file, temp_dir = self.render_video()

        if config["environment"]["interactive"]:
            from IPython.display import HTML, display

            video_bytes = temp_file.read_bytes()
            video_b64 = base64.b64encode(video_bytes).decode()
            video_html = f"""
            <video width="580" height="340" controls>
                <source src="data:video/mp4;base64,{video_b64}" type="video/mp4">
                Your browser does not support the video tag.
            </video>
            """
            display(HTML(video_html))
        else:
            # open the file in the webbrowser
            webbrowser.open(r"file:///" + temp_file.as_posix())
        shutil.rmtree(temp_dir)

__init__

Initialize Manim backend with temporal network validation and configuration.

Sets up Manim configuration parameters including resolution, frame rate, quality settings, and background color. Validates that the plot type is supported (currently only TemporalNetworkPlot).

Parameters:

Name Type Description Default
plot pathpyG.visualisations.pathpy_plot.PathPyPlot

PathPyPlot instance (must be TemporalNetworkPlot)

 required
show_labels bool

Whether to display node labels in animation

 required

Raises:

Type Description
ValueError

If plot type is not supported by Manim backend

Manim Configuration

Automatically configures Manim settings using pathpyG config and fixed defaults:

  • Resolution: From width/height config parameters
  • Frame Rate: Default 15 fps for smooth playback
  • Quality: High quality
  • Background: White background for clarity
Source code in src/pathpyG/visualisations/_manim/backend.py
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
def __init__(self, plot: PathPyPlot, show_labels: bool):
    """Initialize Manim backend with temporal network validation and configuration.

    Sets up Manim configuration parameters including resolution, frame rate,
    quality settings, and background color. Validates that the plot type
    is supported (currently only TemporalNetworkPlot).

    Args:
        plot: PathPyPlot instance (must be TemporalNetworkPlot)
        show_labels: Whether to display node labels in animation

    Raises:
        ValueError: If plot type is not supported by Manim backend

    !!! info "Manim Configuration"
        Automatically configures Manim settings using pathpyG config and fixed defaults:

        - **Resolution**: From width/height config parameters
        - **Frame Rate**: Default 15 fps for smooth playback
        - **Quality**: High quality
        - **Background**: White background for clarity
    """
    super().__init__(plot, show_labels=show_labels)
    self._kind = SUPPORTED_KINDS.get(type(plot), None)
    if self._kind is None:
        logger.error(f"Plot of type {type(plot)} not supported by Matplotlib backend.")
        raise ValueError(f"Plot of type {type(plot)} not supported.")

    # Optional config settings
    manim_config.pixel_height = int(unit_str_to_float(self.config.get("height"), "px"))  # type: ignore[arg-type]
    manim_config.pixel_width = int(unit_str_to_float(self.config.get("width"), "px"))  # type: ignore[arg-type]
    manim_config.quality = "high_quality"
    manim_config.background_color = WHITE

convert_to_gif

Convert rendered MP4 video to animated GIF using FFmpeg.

Uses FFmpeg with optimized settings for web-friendly GIF output: 30 fps for smooth animation, Lanczos scaling for quality preservation, and 1080p resolution maintenance.

Parameters:

Name Type Description Default
filename pathlib.Path

Path to source MP4 file (output GIF uses same path with .gif extension)

 required

Raises:

Type Description
Exception

If FFmpeg conversion fails (logged as error)
Source code in src/pathpyG/visualisations/_manim/backend.py
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
def convert_to_gif(self, filename: Path) -> None:
    """Convert rendered MP4 video to animated GIF using FFmpeg.

    Uses FFmpeg with optimized settings for web-friendly GIF output:
    30 fps for smooth animation, Lanczos scaling for quality preservation,
    and 1080p resolution maintenance.

    Args:
        filename: Path to source MP4 file (output GIF uses same path with .gif extension)

    Raises:
        Exception: If FFmpeg conversion fails (logged as error)
    """
    try:
        subprocess.run(
            [
                "ffmpeg",
                "-i",
                filename,
                "-vf",
                "fps=30,scale=1080:-1:flags=lanczos",
                "-y",
                "-hide_banner",
                "-loglevel",
                "error",
                filename.with_suffix(".gif"),
            ],
            check=True,
        )
    except Exception as e:
        logger.error(f"GIF conversion failed: {e}")

render_video

Render temporal network animation using Manim engine.

Creates temporary directory, configures Manim settings, instantiates TemporalGraphScene, and renders the complete animation sequence. Handles all Manim-specific setup and teardown.

Returns:

Name Type Description
tuple tuple[pathlib.Path, str]

(video_file_path, temp_directory_path) for post-processing

Rendering Pipeline

  1. Setup: Create temporary directory for Manim output
  2. Configuration: Set output path and filename
  3. Scene Creation: Instantiate TemporalGraphScene with data
  4. Rendering: Execute Manim rendering process
  5. Cleanup: Return paths for further processing and returns to original directory
Source code in src/pathpyG/visualisations/_manim/backend.py
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
def render_video(self) -> tuple[Path, str]:
    """Render temporal network animation using Manim engine.

    Creates temporary directory, configures Manim settings, instantiates
    TemporalGraphScene, and renders the complete animation sequence.
    Handles all Manim-specific setup and teardown.

    Returns:
        tuple: (video_file_path, temp_directory_path) for post-processing

    !!! info "Rendering Pipeline"
        1. **Setup**: Create temporary directory for Manim output
        2. **Configuration**: Set output path and filename
        3. **Scene Creation**: Instantiate TemporalGraphScene with data
        4. **Rendering**: Execute Manim rendering process
        5. **Cleanup**: Return paths for further processing and returns to original directory
    """
    temp_dir, current_dir = prepare_tempfile()
    manim_config.media_dir = temp_dir
    manim_config.output_file = "default.mp4"
    self.scene = TemporalGraphScene(data=self.data, config=self.config, show_labels=self.show_labels)
    self.scene.render()
    os.chdir(current_dir)
    return Path(temp_dir) / "videos" / "1080p60" / "default.mp4", temp_dir

save

Render and save temporal network animation to specified file.

Creates high-quality animation video and saves to disk. Supports both MP4 and GIF formats with automatic format detection from filename extension. GIF conversion uses FFmpeg.

Parameters:

Name Type Description Default
filename str

Output file path with extension (.mp4 or .gif)

 required

GIF Conversion

GIF creation requires FFmpeg to be installed and available in PATH. Conversion may take additional time for long animations.

Source code in src/pathpyG/visualisations/_manim/backend.py
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
def save(self, filename: str) -> None:
    """Render and save temporal network animation to specified file.

    Creates high-quality animation video and saves to disk. Supports both
    MP4 and GIF formats with automatic format detection from filename
    extension. GIF conversion uses FFmpeg.

    Args:
        filename: Output file path with extension (.mp4 or .gif)

    !!! warning "GIF Conversion"
        GIF creation requires FFmpeg to be installed and available in PATH.
        Conversion may take additional time for long animations.
    """
    # render temporary .mp4
    temp_file, temp_dir = self.render_video()
    if filename.endswith(".gif"):
        self.convert_to_gif(temp_file)
        temp_file = temp_file.with_suffix(".gif")
    shutil.copy(temp_file, filename)
    shutil.rmtree(temp_dir)

show

Display temporal network animation in interactive environment.

Renders animation and displays inline in Jupyter notebooks using base64 video embedding, or opens in system browser for non-interactive environments. Automatically cleans up temporary files after display.

Source code in src/pathpyG/visualisations/_manim/backend.py
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
def show(self) -> None:
    """Display temporal network animation in interactive environment.

    Renders animation and displays inline in Jupyter notebooks using base64
    video embedding, or opens in system browser for non-interactive environments.
    Automatically cleans up temporary files after display.
    """
    temp_file, temp_dir = self.render_video()

    if config["environment"]["interactive"]:
        from IPython.display import HTML, display

        video_bytes = temp_file.read_bytes()
        video_b64 = base64.b64encode(video_bytes).decode()
        video_html = f"""
        <video width="580" height="340" controls>
            <source src="data:video/mp4;base64,{video_b64}" type="video/mp4">
            Your browser does not support the video tag.
        </video>
        """
        display(HTML(video_html))
    else:
        # open the file in the webbrowser
        webbrowser.open(r"file:///" + temp_file.as_posix())
    shutil.rmtree(temp_dir)
